UniFi Express
Impressively compact Cloud Gateway and WiFi 6 AP that runs UniFi Network. Powers an entire network or simply meshes as an AP.
Technical
| Specification | Details |
|---|---|
| Dimensions | 98 x 98 x 30 mm (3.6 x 3.6 x 1.2") |
| Coverage Area | 140 m² (1,500 ft²) |
| Managed UniFi Devices | 4 |
| Simultaneous Users | 50+ |
| WAN Ports | (1) GbE RJ45 |
| LAN Ports | (2) 1 GbE RJ45 (1G/100M/10M) |
| Form Factor | Compact desktop |
| Security | |
| Stateful Firewall | ✓ |
| Layer 7 Firewall | ✓ |
| DPI & Traffic Identification | ✓ |
| Content Filtering | ✓ |
| Ad Blocking | ✓ |
| VPN & SD-WAN | |
| License-Free SD-WAN | ✓ |
| Site-to-Site VPN | IPsec, OpenVPN |
| VPN Server | Teleport, WireGuard, OpenVPN, L2TP |
| VPN Client | OpenVPN, WireGuard |
| Networking | |
| Dynamic Routing | OSPF |
| Advanced QoS | ✓ |
| Integrated RADIUS Server | ✓ |
| IPv6 ISP Support | ✓ |
| Integrated WiFi | |
| WiFi Standard | 802.11a/b/g/n/ac/ax (WiFi 6) |
| Throughput | 5 GHz: 2.4 Gbps 2.4 GHz: 573.5 Mbps |
| MIMO | 2x2 (DL/UL MU-MIMO) |
| Antenna Gain | 5 GHz: 5.15 dBi 2.4 GHz: 4 dBi |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| Hardware | |
| Max. Power Consumption | 10W |
| Power Method | USB type C (5V DC/3A) |
| Processor | Dual-core ARM Cortex-A53 @ 1 GHz |
| System Memory | 1 GB |
| Weight | 302 g (10.7 oz) |
| Enclosure Material | Polycarbonate |
| Compliance | |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
