UNAS Pro
2U rack-mount NAS with (7) 2.5/3.5" drive bays and 10 Gbps performance designed for large-scale file storage and sharing.
Technical
| Hardware Specifications | |
|---|---|
| Dimensions | 442 x 325 x 87 mm (17.4 x 12.8 x 3.4") |
| Form Factor | Rack mount (2U) |
| Storage Capacity | (7) 3.5" drive bays |
| Drive Support | (7) 2.5"/3.5" HDD or SSD |
| Max. Power Budget for Drives | 135W |
| Max Power Consumption | 160W |
| Power Redundancy | ✓ |
| Power Method |
(1) Universal AC input, 100–240V AC, 3A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 13.91A |
| Power Supply | AC/DC, internal, 200W |
| Processor | Quad-Core ARM® Cortex®-A57 @ 1.7 GHz |
| Memory | 8 GB |
| Management | Ethernet In-Band |
| RF Interface | Bluetooth 4.1 |
| Display | 1.3" touchscreen |
| Weight |
Without brackets: 9.2 kg (20.3 lb) With brackets: 9.5 kg (20.8 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| LED Indicators | Ethernet, SFP+, HDD, RPS |
| Certifications | FCC, CE, IC |
| NDAA Compliant | ✓ |
| Networking | |
| Networking Interfaces |
(1) 10G SFP+ (1) 1G RJ45 |
| Environmental | |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 5% – 95% non-condensing |
| Software | |
| Application Requirements | UniFi Drive Version 1.16.0 and later |
