G5 Dome
Next-gen 2K HD PoE ceiling camera with enhanced dynamic range and low-light performance.
Technical
| General Specifications | |
|---|---|
| Dimensions | Ø109.2 x 64.5 mm (Ø4.3 x 2.5") |
| Weight | 370 g (13.1 oz) 390 g (13.8 oz) with mount |
| Mounting Options | Wall, Ceiling (Included) Junction Box, Arm Mount (Optional) |
| Enclosure Material | Aluminum Alloy, Polycarbonate, Hard-coated Dome |
| Mount Material | Polycarbonate, Stainless Steel |
| Tamper Resistance | IK08 |
| Weatherproofing | IPX4 (While Covered) |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC |
| Camera Performance | |
| Resolution | 2K (4MP) – 2688 x 1512 (16:9) |
| Sensor | 5MP CMOS |
| Field of View | H: 102.4°, V: 54.9°, D: 120.6° |
| Frame Rate | 30 FPS |
| Lens Type | Fixed Focal Length |
| Night Vision | 9 m (30 ft), IR LED with IR Cut Filter |
| Smart Detections | ✓ (People, Vehicles, Animals) |
| Audio & Networking | |
| Audio | Two-Way Audio |
| Networking Interface | 10/100 MbE RJ45 Port |
| Power Method | PoE |
| Supported Voltage | 37—57V DC |
| Max Power Consumption | 5W |
| Video & Processing | |
| Image Settings | Color, Brightness, Sharpness, Contrast, White Balance, Exposure Control, 2DNR, 3DNR, NR by Motion, Masking, Text Overlay |
| Processor | Dual-core Arm® Cortex®-A7 |
| Reset Button | ✓ |
| Environmental | |
| Operating Temperature | -20 to 40° C (-4 to 104° F) |
| Operating Humidity | 0 to 90% Noncondensing |
